Khoom Siv Lub Npe: Countersink Cutter Rau Cov Pwm Tsawg Hauv Pwm
Qauv Zauv: CA
Khoom Par ib metres :
1. Lub npe: WAT
2. Qhov chaw ntawm keeb kwm: Guangdong ntawm Tuam Tshoj
3. Khoom raw: 42CrMo steel
4. Hom: Countersink cutters
5. Ntxig: CCMT060204, CCMT09T304
6. Cov khoom siv ua haujlwm: Tooj, Hlau Cov Hlau, Tuam Hlau, Cov Roj Hlau, Cam Hlau Cam, Pwm Hlau, Stainless Hlau
Specification s :
| PART NUMBER | DIA / D | TXOJ HAUJLWM HOLE / E | HOLE DEPTH / H | CHAMFER A | CHAMFER C | SHANK / D | SIV | INSERT | |
| CA-1218-6.5 | 18 | 12 | 6.5 | 0.8 | 0.8 | 25 | 100 | CCMT060204 | |
| CA-1521-6.5 | 21 | 15 | 1.0 | 120 | |||||
| CA-1622-6.5 | 22 | 16 | |||||||
| CA-2026-6.5 | 26 | 20 | |||||||
| CA-2531-6.5 | 31 | 25 | 6.5 | 1.0 | 0.8 | 32 | 120 | CCMT09T304 | |
| CA-2531-8.5 | 8.5 | ||||||||
| CA-2531-10.5 | 10.5 | ||||||||
| CA-3036-8.5 | 36 | 30 | 8.5 | ||||||
| CA-3036-10.5 | 10.5 | ||||||||
| CA-3541-8.5 | 41 | 35 | 8.5 | 1.0 | 0.8 | 32 | 120 | CCMT09T304 | |
| CA-3541-10.5 | 10.5 | ||||||||
| CA-4046-10.5 | 46 | 40 | 10.5 | 1.0 | 0.8 | 32 | 120 | CCMT09T304 | |
| CA-4248-10.5 | 48 | 42 | 10.5 | ||||||
| CA-4552-10.5 | 52 | 45 | 10.5 | 1.0 | 0.8 | 32 | 120 | CCMT09T304 | |
| CA-4855-10.5 | 55 | 48 | 10.5 | ||||||
| CA-5057-12.5 | 57 | 50 | 12.5 | ||||||
| CA-5562-10.5 | 62 | 55 | 10.5 | ||||||
| CA-6067-15.5 | 67 | 60 | 15.5 | 1.0 | 0.8 | 40 | 130 | CCMT09T304 | |
| CA-7077-12.5 | 77 | 70 | 12.5 | ||||||
| CA-7077-15.5 | 77 | 70 | 15.5 | ||||||
| CA-8088-15.5 | 88 | 80 | 15.5 | ||||||
| CA-8088-20.5 | 88 | 80 | 20.5 | ||||||
| CA-9098-20.5 | 98 | 90 | 20.5 | ||||||
Cim npe nrov: ca txee ntses rau kev pib pwm ua Tuam Tshoj, tuam ntxhab, hoobkas, lag luam, pheej yig
